AVTECH’s Room Alert can help protect your facility and assets by monitoring critical environment factors like temperature, humidity, flood, power, smoke, and more. With models ranging from our compact Room Alert 3 Wi-Fi, all the way through our flagship model, the Room Alert 32E with a capacity for over 32 sensors, AVTECH has a solution for businesses of every size, in every industry!
Gateways
RoomAlert 12ER
The Room Alert 12E/12ER is AVTECH’s mid-range environment monitor. It monitors temperature, plus up to 8 more environment conditions of your choice. Additional dedicated ports let you toggle low-voltage electrical devices.
When conditions exceed your thresholds, Room Alert notifies you right away so you can act quickly.
- Send email and text messages right from the device.
- Trigger the warning LEDs and siren sound on a Light Tower.
- Pair with RoomAlert.com (or other compatible platforms) for even more alerting capabilities.
RoomAlert 4ER
The Room Alert 4E/4ER is AVTECH’s economical environment monitor for more modest spaces. It monitors temperature, plus up to 3 more environment conditions of your choice. It additionally features a dedicated port for direct connection of AVTECH’s Relay Switch or Light Tower.
When conditions exceed your thresholds, Room Alert notifies you right away so you can act quickly.
- Send email and text messages right from the device.
- Trigger the warning LEDs and siren sound on a Light Tower.
- Pair with RoomAlert.com (or other compatible platforms) for even more alerting capabilities.
RoomAlert 32ER
This model is packed with the most capacity for the most sensors. It monitors temperature, humidity and its own main-vs-battery-power status. With room for 30 sensors/accessories each and the capacity to toggle multiple low-voltage electrical devices, it’s got your environment covered.
When conditions exceed your thresholds, Room Alert notifies you right away so you can act quickly.
- Send email and text messages right from the device.
- Trigger the warning LEDs and siren sound on a Light Tower.
- Pair with RoomAlert.com (or other compatible platforms) for even more alerting capabilities.
Sensors
Digital Temperature Sensor
Each AVTECH Digital Temperature Sensor provides real-time temperature values from -67 to 257 degrees Fahrenheit and/or -55 to 125 degrees Celsius. Accuracy is within + / – 2 C degrees.
This is a dynamic sensor that provides temperature values every two seconds and feeds temperature data back to the Room Alert ID box for data logging, alerting and automatic corrective action. This is an instant ‘Plug & Play’ sensor via one of the standard RJ-11 jacks on any compatible Room Alert monitor.
AVTECH offers this sensor with cable lengths of 25′, 50′ and 100′.
Digital Temperature Sensor Range:
- -67 to 257 F (-55 to 125 C)
Digital Sensor Cable Type
- RJ-11 Cable
- Approximately 100′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 4E, 3E & 3W
Temperature & Humidity
Each AVTECH Digital Temperature & Humidity Sensor provides real-time temperature values from -40 to 185 degrees Fahrenheit and/or -40 to 85 degrees Celsius. Accuracy is within + / – 2 C degrees. The humidity range is from 5% to 95% relative humidity (RH) non-condensing. Humidity accuracy is within +/- 4.5% RH at 5 to 59% RH and within +/- 6.5% RH at 60 to 95% RH.
This is a dynamic sensor that provides temperature and humidity values every two seconds and feeds temperature and humidity in real-time data back to the Room Alert ID box for data logging, alerting and automatic corrective action. This is an instant ‘Plug & Play’ sensor via one of the standard RJ-11 jacks on any compatible Room Alert monitor.
AVTECH offers this sensor with cable lengths of 25′, 50′ and 100′.
Digital Temperature Sensor Range:
- -40 to 185 F (-40 to 85 C)
Digital Humidity Sensor Range:
- 5% to 95% RH Non-Condensing
Digital Sensor Cable Type
- RJ-11 Cable
- Approximately 100′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 4E, 3E & 3W
Flood Sensor
Each AVTECH Flood Sensor with attached sensor cable is activated by liquid (i.e. water, fluid, etc.) making contact with the attached Flood Sensor Cable of any length. Once liquid is detected the Flood Sensor triggers an alarm condition allowing the Room Alert hardware, Device ManageR software and/or other monitoring application to send out alerts and/or take automatic corrective action.
This is an instant ‘Plug & Play’ sensor via one of the switch sensor channels on the back of any compatible Room Alert ID box. Cable distance can be extended from the standard 25′ to approximately 900′ by using standard speaker wire, twisted pair or any reliable low voltage 2-wire cable in order to place Flood Sensor and attached sensor cable away from Room Alert unit, on a different floor, above a drop ceiling or under a raised flood.
Power Supply
- 5VDC 1A Adapter
Sensor Cable Type
- 2 wire sensor cable
- Approximately 900′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 7E, 4E, 3E & 3 Wi-Fi
Smoke & Fire Sensor
These AVTECH Smoke Sensors provide real-time recognition of smoke or fire and includes specially designed electronics that allow it to interface with Room Alert products as a switch sensor. Powered by one 9V Alkaline battery (included), these smoke and fire detectors have a bright ‘escape’ light and loud ‘buzzer’ that are triggered if the sensor is activated.
This is an instant ‘Plug & Play’ sensor via one of the switch sensor channels on the back of any compatible Room Alert ID box. Cable distance can be extended from the standard 25′ to approximately 900′ by using standard speaker wire, twisted pair or any reliable low voltage 2-wire cable.
Power Supply
- 9V Alkaline Battery (Included)
Sensor Cable Type
- 2 wire sensor cable
- Approximately 900′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 7E, 4E, 3E & 3 Wi-Fi
Power Sensor
AVTECH’s Power Failure Sensor provides real-time recognition of a power source going off or coming on. Common use is as a generator sensor, monitoring the power supply of a main, 3 phase, UPS or backup generator source.
Users will often install multiple Power Sensors so they can be immediately informed when one source fails and then immediately informed that the back up supply has taken over. Because AVTECH products allow notification when alert conditions are resolved, users will know immediately when conditions return to normal.
This is a switch sensor that comes complete with its own AVTECH 5V International Power Adapter that plugs directly into the power source being monitored. The power adapter size is very small and allows for use on any outlet, power bar, rack or UPS. This is an instant ‘Plug & Play’ sensor via one of the switch sensor channels on the back of any compatible Room Alert monitor. Cable distance can be extended from the standard 25′ to approximately 900′ by using standard speaker wire, twisted pair or any reliable low voltage 2-wire cable.
Power Supply
- 5VDC 1A Adapter
Sensor Cable Type
- 2 wire sensor cable
- Approximately 900′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 7E, 4E, 3E & 3 Wi-Fi
Room Entry Sensor
Each AVTECH Door Entry Sensor provides real-time recognition of a door or cabinet being open. Standard use is to mount the wired sensor to the frame of a door. Then, mount the matching actuator opposite of the sensor on the door itself. When the door opens, the two components separate and the sensor trips.
This is an instant ‘Plug & Play’ door entry alert sensor via one of the switch sensor channels on the back of any compatible Room Alert ID box. Cable distance can be extended from the standard 25′ to approximately 900′ by using standard speaker wire, twisted pair or any reliable low voltage 2-wire cable.
Power Supply
- Monitoring Unit
Sensor Cable Type
- 2 wire sensor cable
- Approximately 900′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 7E, 4E, 3E & 3 Wi-Fi
Motion Sensor
Each AVTECH Motion Sensor is a movement sensing device specially equipped with additional electronics that allow it to interface with any compatible Room Alert ID box. The motion sensor is powered by a 12V DC power supply and is designed to detect movement up to 35′ away with a cone coverage of approximately 84 degrees wide.
This is an instant ‘Plug & Play’ sensor via one of the switch sensor channels on the back of any compatible Room Alert ID box. Cable distance can be extended from the standard 25′ to approximately 900′ by using standard speaker wire, twisted pair or any reliable low voltage 2-wire cable.
Power Supply
- 12V DC Switching Power Supply w/5′ cable (Included)
Sensor Cable Type
- 2 wire sensor cable
- Approximately 900′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 7E, 4E, 3E & 3 Wi-Fi
Water Tank Level Sensor
AVTECH’s Water Tank Level 1 Sensor (NC) monitors the rise and fall of water in a container (i.e. typically a large tank). The float and control weight are composed of chemically-resistant polypropylene; the 16′ cable is coated with rugged PVC. Because this sensor uses a dual-point switch and differential height between switch states, you can use just one sensor to monitor two levels… both high and low.
Dimensions of the float switch are 5.1″ H x 3.0″ W. The control weight is 4″ H x 2.25″ W. The 16′ attached cable with PVC coating has a protection rating of IP67 and NEMA 6. The switch state differential range is a minimum of 10″ and a maximum of 50″. Please see the Installation Note for more information.
Tank Sensor Cable Type
- Low-voltage 2-wire, PVC coated, IP67 NEMA6
Power Supply
- Monitoring Unit
Sensor Cable Type
- Low-voltage 2-wire speaker cable
- Approximately 900′
Compatible Products
- Room Alert 32W, 32E, 26W, 26WO, 24E, 12E, 11E, 7E, 4E, 3E & 3 Wi-Fi
Accessories
Light Tower w/ Audio
The AVTECH Light Tower w/Audio is designed to enhance the alerting capabilities of the Room Alert 32W, 32E, 12E, 4E or 3E monitors to include visual and audible alarm when an issue or event occurs. The visual alarm warning lights and audio alerts can also be turned on or off automatically or manually via the Room Alert web interface, AVTECH’s Device ManageR software and SNMP Trap or SNMP Set commands. Any Room Alert or Axis camera on the network can enable or disable the lights or audio. The light and audio tower does not need to be directly attached to that unit. This capability allows the Light Towers to be mounted in any location where the lights are highly visible and trigger from across the network. Lights can be activated by alarms detected by sensors connected or by other devices remotely across the network.
The Light and Audio Tower is connected to the Room Alert 4E via the Light Tower Connection Port on the back of the Room Alert 4E monitor. Room Alert 32W, 32E, 12E and 3E monitors require a Light Tower & Relay Adapter (which includes a Relay Switch) in order to connect the Light Tower. The Light Tower w/Audio has an adjustable audio alarm with an intensity range of 0 dB to 95 dB (at 1m). It can be adjusted by simply unscrewing the cover or removing the center plug. The Light w/Audio tower comes standard with a 15′ cable that connects via easy ‘twist & click’ connectors. It can be extended to just over 100′ with AVTECH’s 25´ Light Tower w/Audio Extension Cable ONLY.
External Light Tower
- Yes, Red-Yellow-Green w/Audio
Oscillation Frequency
- 2.7 KHz +/- 50Hz (Max Intensity 95 dB @ 1m)
Sensor Cable Type
- AVTECH Custom Cable
- 15′ (Light Tower w/Audio Extension Cable Available)
Maximum Sensor Cable Length
- Approximately 100′
Compatible Products
- Room Alert 4E. Room Alert 32W, 32E, 12E, & 3E with Light Tower & Relay Adapter
Light Tower - Relay Adapter
The AVTECH Light Tower & Relay Adapter is required to connect the Light Tower, Light Tower audible and visual alarm or the Relay Switch Sensor to AVTECH’s Room Alert 32W, 32E, 12E or 3E environment monitors. It also includes one (1) relay switch that can be used to turn on/off low voltage devices via the Room Alert web interface, Device ManageR or automatically in response to an alarm condition going in or out of an alert stage. Common uses for this relay include connecting to a building alarm panel or other notification system to automate advanced alerting and response to static building alarms that do not notify staff. Users can also connect it to a generator, back up HVAC unit, fan or water pump to turn it on/off in response to an alert condition. The built-in relay supports loads up to 0.3A at 125VAC or 1A at 24VDC.
This is an instant ‘Plug & Play’ adapter that connects directly into the ‘Light Tower / Relay’ Port on the Room Alert 32W, 32E and 12E monitors, or the Room Alert 3E via the included 25´ RJ-11 Cable, and to a Light Tower or Relay Switch Sensor via a connection cable. Connect the relay by using standard speaker wire, twisted pair or any reliable low voltage 2-wire cable. The AVTECH Light Tower & Relay Adapter is ONLY compatible with AVTECH’s Room Alert 32W, 32E, 12E and 3E at this time, or Relay Switch Sensor. A 5V 1A International Power Adapter is included that provides independent power to the attached devices.
Relay Output
- 1
Maximum Relay Load
- 0.3A at 125VAC, 1A at 24VDC
Sensor Cable Type
- 2 wire sensor cable
Maximum Sensor Cable Length
- Approximately 100´
Compatible Products
- Required For Connection Of Light Towers To Room Alert 32W, 32E, 12E and 3E
